Post-Processing

Scalable, Automated SLA Post-Processing

Form Wash L V2 streamlines large-format SLA post-processing with a fully automated cleaning solution designed for production and high-throughput environments. By delivering consistent, repeatable results with minimal hands-on time, it helps teams protect part quality, reduce manual labor, and keep workflows moving efficiently from print to finish.

Have a Question?

Your Ultimate Solution for Professional Post-Processing

Elevate your powder-based 3D printing post-processing with Fuse Blast, a fully automated cleaning and polishing solution. Seamlessly integrated into the Fuse Series ecosystem, Fuse Blast delivers fast, consistent results, cleaning a whole build chamber in just 15 minutes.

With optional polishing capabilities, you achieve smooth, semi-gloss, and dye-ready surface finishes, ensuring professional-grade parts every time. Say goodbye to manual labor and hello to streamlined post-processing with Fuse Blast.

Key Features & Benefits

Automated SLA Washing

Form Wash L automates resin removal for SLA 3D prints, delivering smooth, clean, high-quality parts with minimal hands-on effort.

Set-It-And-Forget-It Convenience

Use pre-programmed wash profiles or save custom settings to streamline your workflow.

Integrated Solvent Monitoring

An embedded solvent monitor helps you maintain peak cleaning performance by alerting you when it’s time to replace the solvent.

Adaptable to Build Platforms

Easily wash large parts or batches by accommodating one Form 3L build platform or two Form 3 platforms with the included adapter.

Consistent, Warp-Free Results

After washing, parts are automatically lifted from solvent to air dry, preventing over-soaking and part distortion.

Technical Specifications

Features	Form Wash V2	Form Wash L V1	Form Wash L V2
Printer Compatibility	Form 4, Form 4B, Form 3/+, Form 3B/+, Form 2	Form 3L, Form 3BL, Form 3/+, Form 3B/+, Form 2	Form 4L, Form 4BL, Form 4, Form 4B, Form 3L, Form 3BL, Form 3/+, Form 3B/+, Form 2
Dimensions (W x D x H)	31.5 x 29.3 x 40.5 cm 12.4 x 11.5 x 15.9 in Height when open: 71.4 cm (28.1 in)	78.0 x 46.0 x 67.0 cm 30.7 x 18.1 x 26.4 in Height when open: 113 cm (44.5 in)	78.0 x 46.0 x 67.0 cm 30.7 x 18.1 x 26.4 in Height when open: 113 cm (44.5 in)
Weight	8.6 kg (without solvent) 18.9 lbs (without solvent)	56.7 kg (without solvent) 125lbs (without solvent)	56.7 kg (without solvent) 125lbs (without solvent)
Bucket Volume	14.4 L 3.8 US gal	37.9 L 10.0 US gal	43.0 L 11.4 US gal
Maximum Part Size	20 x 14.5 x 19.5 cm 7.9 x 5.7 x 7.6 in	33.5 x 20 x 30 cm 13.2 x 7.9 x 11.8 in	35.3 x 20 x 29.6 cm 13.9 x 7.9 x 11.7 in
Suggested Operating Environment	Suggested 18—28 °C Suggested 64—82 °F	Suggested 18—28 °C Suggested 64—82 °F	Suggested 18—28 °C Suggested 64—82 °F
Agitation Method	Magnetically coupled impeller	Magnetically coupled impeller	Magnetically coupled impeller
Included Accessories	a. Wash Bucket b. Wash Basket c. Hydrometer d. 2x Platforms Mounts	a. Wash Bucket BRS b. Wash Basket BRS c. Electric Solvent Pump BRS d. Flush Cutters BRS e. Rinse Bottle BRS f. Gloves BRS i. Form 3 Build Platform Adaptor BRS	a. Wash Bucket b. Wash Basket c. Electric Solvent Pump d. Flush Cutters e. Rinse Bottle f. Gloves
Power Requirements	90–240 V 2.0 A 50/60 Hz 50 W	Input (NA) 100 - 120 VAC, 50-60Hz, 1A Input (EU) 220 - 240 VAC, 50-60Hz, 1A	Input (NA) 100-120 VAC, 50-60 Hz, 1 A Input (EU) 220-240 VAC, 50-60 Hz, 1 A
Compatible Solvents	IPA, TPM, Water, Formlabs Resin Washing Solution	IPA, TPM, Water, Formlabs Resin Washing Solution	IPA, TPM, Water, Formlabs Resin Washing Solution

A Premier Industrial Design Studio Leverages Formlabs

Vital Auto, a top-tier industrial design studio specializing in automotive design, serves major clients like Volvo, Nissan, McLaren, and Lotus.

They utilize Formlabs Form 3L SLA printers and Fuse 1 SLS printers for high-fidelity prototypes and end-use parts. Their materials range from Elastic 80A Resin for prototype door seals to Nylon 12 for rugged components like air ducts, all crafted with precision and expertise.

Adaptable to Build Platforms

Seamlessly switch between build platforms with adjustable platform mounts, configurable at various heights and widths.

Printer Generation	Applicable Build Platforms	# Build Platforms That Can Fit on Form Wash L V2
Form 2 Form 3/B/+	Standard Build Platform Build Platform 2 Stainless Steel Build Platform	2
Form 3L/BL	Form 3L Build Platform Form 3L Build Platform 2L	1
Form 4/B	Form 4 Build Platform Form 4 Build Platform Flex	2
Form 4L/BL	Form 4L Build Platform Form 4L Build Platform Flex	1

Keep On Learning

Formlabs Resources

Frequently Asked Questions

What is included with Fuse Blast?

Fuse Blast comes with the following accessories:

Transfer container
Control pedals
ESD wrist strap
7mm socket wrench
Blast orifice (3mm)
Blast orifice (4mm)
T-20 driver
Floor mat

Is Fuse Blast only for Formlabs?

No, you can use this de-powdering system for other powder-based technologies as well.

What is the smoothing option?

The smoothing option is a post-processing technique for smoothing the surface of 3D printed parts. It involves using an abrasive blasting process to remove layer lines and imperfections, resulting in a smoother finish on the part’s surface.

How does Fuse Blast benefit existing Formlabs 3D Printing users?

Users of other Formlabs 3D printing solutions can integrate the Fuse Blast Smoothing Option into their workflow by incorporating it as a post-processing step after printing. Once the desired parts are printed using Formlabs printers, they can be transferred to the Fuse Blast unit for smoothing. This process enables users to achieve a polished finish on their 3D-printed parts, enhancing their aesthetic appeal and functional performance.

Can I achieve professional-grade results with Fuse Blast without using Fuse Sift?

Yes, Fuse Blast allows you to clean parts extracted from the cake without prior de-powdering, reducing Fuse Sift time to 5-10 minutes. However, we recommend using Fuse Sift and Fuse Blast together for optimal powder management and part cleaning workflows.

Is polishing possible with Fuse Blast?

Yes, Fuse Blast can polish parts using specialty plastic media with the drop-in polishing upgrade. This feature will be available in H1 2024, allowing for a smooth, semi-gloss, and dye-ready surface finish.

How long does it take to post-process parts with Fuse Blast?

Typically, the post-processing time on the Fuse Series ecosystem ranges from 15 to 30 minutes, depending on factors like material used, part geometry and desired powder reclaim. This includes extracting parts, cleaning and optional polishing.

What is the labor requirement for operating the Fuse Blast?

Fuse Blast is an automated solution that minimizes manual labor. Users simply transfer parts from the Fuse Sift to the Fuse Blast, press the “Start” button, and let the system handle the rest. Manual cleaning modes are available for delicate or large parts.

Is the Fuse Blast ATEX certified?

No, ATEX certification is not required as the Fuse Blast is not intended for use in potentially explosive environments. However, it adheres to safety standards for dust containment and ventilation, ensuring a safe operating environment.
